It is common to think of a system as composed of a view, the application intelligence, and a data store. This is the basis for the three-tier model:

• View
  Presents application information to the user augmented with visual styles and provides controls for the user to adjust the view and send requests to the application.
• Application
  Is responsible for supporting all the activities of the application in response to user requests, perhaps based on "Business Logic", and drawing data from the data store.
• Data Store
  Holds, organizes, and provides editing facilities for data that supports the application.

Many of the Graphical User Interface (GUI) frameworks - WinForms, WPF, Asp.Net, gtk, etc - encourage you to tightly bind the view to the application processing and datastore. They do this through wizards, hundreds of examples, and a lot of documentation.

For simple applications that have a single view, simple logic, and one source of data, that's quick, easy, and perfectly reasonable implementation approach. But, many applications need:

• Multiple Views

  Orders, inventory, customers, schedule, ...
• More than one "Business Case"

  Managing inventory, processing orders, billing, ...
• Multiple sources of data

  Orders db, shippers web service, distributers inventory, ...

For these more complex situations it becomes important to avoid tight bindings between layers of the system. We want to be able to add a new view that simply uses services defined by the application layer. We want to add additional business processing by simply adding a new service that uses existing services provided by the data layer. And we don't want the new business process to need to know the implementation details of the data service.

We achieve this by two simple but powerful ideas:

• Define abstractions - models - for each of the three layers

  • View Model
    Provides classes with public properties, designed to support binding to UI controls. These classes gather data from the application by interacting with application services and they support notification and enumeration protocols needed by the view's controls. This keeps the view simple and independent of other views. Each view simply depends on the view model for support.
  • Application (Business) Model
    Provides classes that model the business or computation required for the application. These should represent things familiar to the user of the system, e.g., customers, orders, etc. The states of these objects depend upon the data layer to support persistence. When created they initialize by making queries into the data layer. When disposed they serialize their state back to the data store, using services provided by the data layer.
  • Data Model
    The data layer provides a set of objects that wrap db tables, or stored procedures, or XML files. They handle connection management and the create, read, update, and delete (CRUD) operations on the stored data. This is essentially an object to relational mapping. Several frameworks have been created to support this, e.g., Hibernate, Entity Framework, LinqToSql, ...
• Use Dependency Injection to avoid concrete couplings between layers
  Dependency Injection is a simple extension of the Dependency Inversion Principle (DIP) that is used to build components. DIP says that clients should not couple to servers. Instead the clients use interfaces implemented by the servers. That way they both depend on the contract specified by the interface, not on implementation details. One more thing is required by DIP - the clients are not allowed to directly create concrete server objects. So DIP requires the use of an Object Factory to support the server abstraction.

  Dependency Injection goes just a little further with the object factory - it provides a container to hold and manage created instances, perhaps using an object pool, and supports the registration of new interfaces and their concrete implementations. This makes the server's functionality extensible via plugin components. The Unity Framework, part of the Microsoft Patterns & Practices material on unity.codeplex.com is an example of the genre.

• Service Interfaces

  The service interfaces may appear at each layer, determined by the complexity of the application. So, the view uses service interfaces provided by the View Model and bound to internal VM objects. Similarly, the VM uses service interfaces provided by the Data Model bound to data model objects.
• Object Factories

  The View Model objects that implement its interfaces are created by the view through simple calls to the VM container. The Data Model objects that implement its interfaces are created by the View Model by calling into the data model container. This avoids reintroducing concrete bindings between the layers by letting the Object Factory handle those concrete bindings, keeping clients bound only to the service abstraction.

There are several patterns that arrange these ideas in slightly different ways:

• Model View Controller MVC
• Model View ViewModel MV VM
• Presentation Model PM

The Model View Controller, in its original form, used the controller primarily to dispatch event actions in the view to handlers in the model. In Frameworks like WinForms and WPF that dispatching happens in the view in a framework specific way. We, however, can simply delegate calls in the event handlers to the viewmodel using its service interfaces.
